Sorcerer Decoder Download

***This version is VIRUS FREE ***

One of my hobbies is decoding Digital RF transmissions from across the spectrum. Whie searching for a decoder for a particular mode (that is only commercially available so it seems) I came across this decoding software and decided to give it a try. Apparently it is abandonware or a part of a formally commercial software company that is no longer in business. So I'm not going to worry too much about copyright issues since there is no one to raise a stink anymore. (If this is your software and you want it removed from my site please send me a message with all the appropriate DMCA takedown information, and once verified it will be removed. Fake notices won't work folks, so don't bother.)

Here are the particulars from the site where I originally found it (Radioaficion Ham Radio )

SORCERER is a collection of decoders for modes found in the ELF-SHF range.  These work in tandem with proprietary intelligent bit parsers automatically identifying targets of interest.  (ie  –  country and specific service as well as identifying data link protocols, compression schemes, file formats, and cryptographic formats in use.

These feature:

    No proprietary hardware
    The most comprehensive collection of current, on-air modes (no defunct modes!)
    Superb demodulation, decoding and parsing of ELF-SHF modes
    Run multiple decoders simultaneously
    Unmatched decoder performance in weak/poor conditions
    Hundreds of parsers always available – run multiple per decoder
    High-speed constellation display
    Offline or Online Analysis
    Flexible variety of outputs to support cryptanalysis
    Continuous development – new modes added throughout the year
    Custom demodulators, decoders and parsers available upon request

Sorcerer offers hundreds of decoders for current, on-air modes ranging from ELF to SHF, terrestrial, air, naval and satellite modes . New modes are added on a monthly basis.

Supported Narrowband Receivers
AOR AR-5000
Cubic R-2307, R-2345, R-2411, R-3030,
R-3030A, R-3050, R-3080, R-3090, R-3550,
R-3580, R-4000S, LCR/SMR-2000, LCR/
SMR-2400, LCR-3000, LCR-3400, SMR-3000,
SMR-4000, CDR-3250, CDR-3280
Drake R-8, R-8A, R-8B
DRS WJ-8710A, WJ-8711, WJ-8711A, WJ-
8712A, WJ-8712P, WJ-8723-4, HF-1000A,
WJ-8611
Icom R71, R71A, R72, R75, R7000, R7100,
R8500, R9000, IC-R1500, PCR-1500,
IC-R2500, PCR-2500
JRC NRD-535, NRD-535D, NRD-545, NRD-
545DSP
R&S EK890, EK895, EK896, EK2000, EB200
Racal RA3721, RA3722, RA3723, RA3724,
RA2091, RA2309B, RA2294, RA2295F,
RA2296, RA830JD, RA3791, RA3792, RA3793,
RA3794, RA3796, RA6775, RA6778C,
RA6793, RA6793A, RA6790GM/R-2174A
Selenia S-1022/N
Selex HF2000
Ten-Tec RX-330, RX-331, RX-340, RX-350
Titan MD-405A

Supported Wideband Receivers

    RFSpace SDR-14, SDR-IQ, SDR-IP
    SRL-LLC QS1R
    Microtelcom Perseus

inputs

    AF – real-time or WAV fle
    I&Q

outputs

    Decoded Text to Screen
    Decoded Text to ASCII fle
    Demodulated Bit Stream to Screen
    Demodulated Bit Stream to ASCII fle
    Demodulated Bitstream to Hexadecimal

lf-mf-Hf modems + teleprinters
AN/PRC-137F Burst Message*
AN/PRC-150C Burst Message*
ASCII – ITA5
AT-3004D/AT-3104* AT-3004D/3014D
Baudot – ITA2 Synchronous
Baudot – ITA2 Asynchronous
BULG8 (Bulgarian 8FSK ARQ
BPSK31 BPSK63
BPSK125 BPSK125F FEC
BPSK220 BPSK220F FEC
CHU Time Signal CIS 100-750 FSK*
CIS 3VFT FSK 100bd (N-M-W)*
CIS 300bd Burst FSK*
CIS MFSK16 CIS MFSK20
CIS11 (RFSHEM
Codan 9001 / 9002 / 3012 / 3112*
Coquelet-8 Coquelet-8 ARQ
Coquelet-8 FEC Coquelet-13
Coquelet-13 ARQ Coquelet-13 FEC
CV-786 Asynchronous
DCF77 Time Signal
DOMINO (all submodes)
DPRK-ARQ*

DPRK 600 bd FSK* EFR Telemeter
Facsimile (FAX) 60-90-120-240 LPM
Facsimile (FAX) B&W – Gray Scale
France-Inter Time Signal
Globe Wireless Dataplex Marker
Globe Wireless FSK & PSK
G-Tor ARQ G-Tor FEC
Greek 145bd 1265 Hz FSK*
Grintek DT-309
Harris RF-3560 PSTN TIU
Hart PRIME
Hellschreiber – Basic Hellschreiber – FELD
Hellschreiber – FM Hellschreiber- MT
Hellschreiber- Duplo Hellschreiber – PSK
HF Datalink (HFDL) ARINC 635
IRA-ARQ (ASCII-ARQ)
Israeli Tadiran Burst Message System*
Italian FSK Burst 600 bps*
Italian FSK 300/600 bd*
Italian FSK 1200 bd*
IRA-ARQ (includes Zip archive recovery)
MD-513B 16PSK MT63
MD-674 Asynchronous FSK
MD-1061 16PSK MD-1239 16PSK
MD-1268 16PSK MFSK8 & 16
Mil-Std 188-110A App A 16DPSK
Mil-Std 188-110A serial
Mil-Std 188-110A serial HRS variant
Mil-Std 55529A NB Asynchronous FSK
Mil-Std 55529A WB Asynchronous FSK
MSF Rugby Time Signal
Nokia M85200 M90*
OLIVIA (all submodes)

Packet AX.25 HF
Pactor-I Pactor-I FEC
Pactor-Selcall Pactor-II & III
Piccolo (all submodes)
PRC/PLA MFSK32* PRC/PLAADF 3+3
PRC/PLAADF 4+4 PRC/PLAADF 4FSK*
PSK10 QPSK31 FEC
QPSK63 FEC RSX.25*
RAO-UES 200-340 FSK*
RTCM SC104* Russian Chayka*
Russian 8FSK 200bd
Russian 150bd Burst Message System*
Singapore Tadiran Burst Message System*
Sitor-A/B 109.5bd ARQ/FEC
Sitor-A ARQ Sitor-B FEC
Sitor-A Phasing Sitor-B NAVTEX
SSTV VIS SSTV 2-8 B&W
SSTV 6-12 B&W SSTV 8-36 Color
SSTV 10-24 B&W SSTV 12-72 Colo
SSTV 14-36 B&W SSTV 32 Martin M4
SSTV 36 Martin 3 SSTV 40 Martin 2
SSTV 44 Martin 1 SSTV 48 Scottie 4
SSTV 52 Scottie 3 SSTV 56 Scottie 2
SSTV 60 Scottie 1 SSTV 76 Scottie DX
SSTV 126 Martin 1 SSTV 18 SC-1 8 sec
SSTV 22 SC-1 16 sec SSTV 30 SC-1 32 sec
SSTV 130 MP73 SSTV 131 MP115
SSTV 132 MP140 SSTV 133 MP175
STANAG 4285 serial STANAG 4481
STANAG 4529 STANAG 4529 HRS
STANAG 5514 SATIR*
Swiss 2VFT 100 bd*
Turkish 600-400 FSK*
Ukrainian Army 6VFT R.38 modem*
USVI WWV Time Signal
WWVH Time Signal

Selcall-ale-alm-aliS modes
ARQ-FAE CIS-ALE 150
Barrett Selcall-Beacon-GPS-Status-Emergency
Codan Selcall-Beacon-GPS-Status-Emergency-
TelCall-PageCall
CCIR M.493 v.1-9 Selcalls
DSP-9000 Type-1 & 2 Selcall
Jenal/Schuemperlin SC-2 & 3 Selcall
Jenal SC-32 & 33 & 51 Selcalls
Mil-Std 188-141A ALE (1G + 2G)
Mil-Std 188-141B ALE (2G)
Mil-Std 188-141B ALE (3G – all 6 burst
waveforms)
Necode 321AR & 322AR Selcalls
Necode 322ARX Selcall
Q-Mac HF90 Selcall
Spectratek SR-3 Selcall
SGC Selcall
Tadiran AutoCall
Thales HF90 Selcall-Beacon-GPS-Status-
Emergency
Thales Skymaster ALM*
PRC 8FSK ALE*
R&S ALIS v10 & 30 & 40
R&S ALIS v50 Hopping
R&S ALIS v50 Adaptive+Hopping
R&S ALIS-2000
RN Bikini Type-1 Alert/Selcall
RN Bikini Type-2 Alert/Selcall
Russian ALE
Thales Skymaster ALM*
WA2 Selcall-Telcall
Yaesu/Vertex Standard 600 Selcall
Yaesu/Vertex Standard 1210 Selcall

VHf-UHf modems
ACARS VHF CCIR-1 Tonal System
CCIR-2 Tonal System CCIR-7 Tonal System
CCITT Tonal System CTCSS Tonal System
DCSS – PL/DPL Tonal System
DTMF Tonal System DZVEI Tonal System
EEA Tonal System EIA Tonal System
ERMES Paging EURO Tonal System
GMDSS M.825 VTS Selcall
M.1371-1 AIS 9600bd
MDC-1200 MODAT Tonal System
NATEL Tonal System POCSAG Paging
AX.25 Packet VHF 9600bd
PZVEI
Super POCSAG Paging
ZVEI-1 &2 & 3 Tonal Systems
Satellite modems
COSMOS NOAA Telemetry
Facsimile (FAX) APT Weather
SARSAT L-Band
Vaisala RS-92AGP/SGP

minimum system configuration:

    PENTIUM-CLASS CPU 1 GHZ+
    128MB+ RAM
    STANDARD AC97 SOUNDCARD
    WINDOWS 98, 98SE, 2000, XP, 7


CLICK HERE TO DOWNLOAD – 943.75KB – From My Server – Guaranteed Virus Free – VIRUS TOTAL info shows 3 hits for a trojan, but those are false positives.

Download From Mediafire – At Your Own Risk

Click Here To Download Installation Guide – 733.60KB – PDF- From My Server

Happy Decoding!

73 de KD0CQ

About the Author

kd0cq
Chris - KD0CQ (formerly KB0TLW) has held an amateur (ham) radio license since 1994 and is stubbornly grasping onto his Advanced class operator status. His professional experience includes Network and Systems Administrator, Network Security, and Electronics Engineer. Sometimes even a little bit of web development. mail: chris at kd0cq dot com

53 Comments on "Sorcerer Decoder Download"

  1. Didn't find any virus or trojan in the .exe, but for some reason the application will open, but no window appears. I am using Win7

  2. In reading the install manual, it says it needs a USB dongle as part of the licensing. The web site for the original vendor is not longer valid. Any idea how to solve the dongle issue? My guess is that it will not run without a dongle.

  3. Hi,

    Very sorry to trouble you but very little seems available for further info on SORCERER V1.0.1

    I noticed your download site for Sorcerer, and gave it a go.

    When up and running I can get the spectrograph showing well, selecting an  appropriate mode with good known signal from SDR#/Funcube Pro+ , the yellow bandwidth markers come up, the selected mode appears in the bottom left corner of the screen, but no further screen appears as shown in your installation & running document. Is it possible that I' m missing some files, The total file for the app is 958Kb.



    Best regards



    Mike Austin

    Bristol – UK





  4. Hey, looks very very handy and powerful. Are you planning adding support for Funcube dongle pro plus ?

  5. Hello expensively om, I installed(settled) your software which is great.
    I saw in the textbook(manual worker) installation that is needed a dongle but I how see making and in what I could get myself a license(Bachelor's degree)?

    With my thanking 73 F5STO

  6. Your Comments  Still trying to down-load the p0rogram!

  7. Hi,

    awfully sorry to report that sorc. v1.01 exe does not want to run on my Acer laptop Win7. Everytime I hit the exe it just "parks" the hat-icon on the task bar but the px itself does react. On my slow old Win XP it runs without problems. Would you have a guess on how to get things running!?

    Thank you in advance for your time.

    73s Ulrich from HB



  8. It's just a bug in the software.

    Simple fix:

    sorcerer and Win7

    Run-> RegEdt32
    Find this key –> HKEY_CURRENT_USER\Software\Sorcerer
    Find the (4) values starting with "Main" == MainH, MainW, MainX, MainY
    Right-click on each of these and select Delete.
    Close RegEdt32
    Relaunch Sorcerer.
    Fixed.
